Disc Setback - Outside Edge of Disc to End of Wheel Opposite Hub Dim. C (in.): 3

Disc Shape (Hub side): Convex

Hub Length Dim. B (in.): 1-3/16

Keyway (in.): None

No. of Blades: 54

No. Set Screws: 1

Nominal Hub Bore Shaft Size Dim. E (in.): 1/2

Nominal Size (in.): 11 x 6

Outside Edge of Disc to Outside End of Hub Dim. A (in.): 2-1/8

Overall Diameter Dim. D (in.): 11-15/16

Overall Width Dim. W (in.): 6-1/16

Rotation Direction (Facing Hub): CW

Shipping Weight Actual (lbs.): 6.38

Shipping Weight Dimensional (lbs.): 13.09

Shipping Height (in.): 14.50

Shipping Length (in.): 15.35

Shipping Width (in.): 14.70
