No. of Poles: 4

Motor Type: PSC

Enclosure: OAO

HP (Max.): 3/4

Voltage: 208-230

Mounting: Resilient Ring Mounting, Extended Clampbolts

Speeds: 3

Hz: 60

Rotation: REV

RPM Range: 1625

NEMA Frame Size: 48

Phase: Single

Standards: UL/CSA

FLA: 4.5

Bearing: Sleeve

Lead Length (in.): 26

Thermal Protection: Yes

Ambient Deg C: 40

Ins. Class: B

Shaft Dia. (in.): 1/2

Capacitor Included: No

Shaft Length (in.): 4.00

Capacitor Rating: 7.5/370

Service Factor: 1.0

Duty: Continuous

Brand: Regal

Pack Qty: 1

Length: 14.00 in.

Width: 6.80 in.

Height: 7.00 in.

Weight: 18.0000 lbs

Harmonized Tariff Code: 8501403040
