Jard 22585 - 1/3HP 115V 1075RPM 3SP REV
Brand:
SKU
22585
No. of Poles: 6
Motor Type: PSC
Enclosure: OAO
HP (Max.): 1/3
Voltage: 115
Mounting: Belly Band, Resilient Ring
Speeds: 3
Hz: 60
Rotation: REV
RPM Range: 1075
NEMA Frame Size: 48
Phase: Single
Standards: CUL
FLA: 6.1
Bearing: Ball
Lead Length (in.): 32
Thermal Protection: Auto
Ambient Deg C: 40
Ins. Class: B
Shaft Dia. (in.): 1/2
Capacitor Included: No
Shaft Length (in.): 4.5
Capacitor Rating: 5/370
Service Factor: 1.0
Duty: Continuous
