Product Specifications

Type: Single Stage

Ignition Type: Standing Pilot

Type of Gas: Natural

Inlet/Outlet Size (in.): 3/4 in. x 3/4 in.

Body Pattern: Straight through with integral tapping; with flange

Opening Characteristics (standard, step): Standard

Capacity @ 1 in. p.d.: 200,000 BTU/hr; 30,000 BTU/hr minimum

Pressure Ratings: ½ psi, or 3.5 kPa

Pressure Regulator Setting: 3.5 in. wc (psi), or 0.87 kPa

Pilot Gas Outlet: Compression fitting for 1/4 in. OD tubing

Pressure Tapping: 1/8 in. NPT with plug

Electrical Connections: 1/4 in. quick-connect male terminals

Electrical Ratings: 24 Vac

Frequency: 60 Hz

Anticipator Setting: 0.7 A

Temperature Range: 0° to 175°F, or -18° to +79°C

Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically

Dimensions (in.): 5 3/8 in. high x 4 1/16 in. wide x 2 11/16 in. deep

Dimensions (mm): 135 mm high x 104 mm wide x 69 mm deep

Approvals, American Gas Association IAS: AGA Design Certified: File No. L2025006.

Approvals, Canadian Gas Association: CGA Design Certified: File No. L2025006.

Fuel Type: Natural Gas

Body Pattern: Straight-Through with Flange

Voltage: 24v

Capacity (BTU): 200000

Inlet Size: 3/4"

Outlet Size: 3/4"

Ignition Type: Standing Pilot
