Compatible with ECO connector.

Product Specifications

Type: Single Stage

Ignition Type: Standing Pilot

Type of Gas: Natural

Inlet/Outlet Size (in.): 1/2 in. x 1/2 in.

Body Pattern: Straight-through

Opening Characteristics (standard, step): Standard

Capacity @ 1 in. p.d.: 130,000 BTU/hr; 20,000 BTU/hr minimum

Pressure Ratings: ½ psi, or 3.5 kPa

Pressure Regulator Setting: 3.5 in. wc (psi), or 0.87 kPa

Pilot Gas Outlet: Compression fitting for 1/4 in. OD tubing

Pressure Tapping: 1/8 in. NPT with plug

Electrical Connections: Combination screw and 1/4 in. male quick connects

Electrical Ratings: 24 Vac

Frequency: 60 Hz

Anticipator Setting: 0.5 A

Temperature Range: 0° to 175°F, or -18° to +79°C

Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically

Dimensions (in.): 5 3/8 in. high x 4 1/16 in. wide x 2 11/16 in. deep

Dimensions (mm): 135 mm high x 104 mm wide x 69 mm deep

Includes: 1/2 in. x 3/8 in. reducer bushing; 39369014 bag assembly-3/4 in. straight flange with O ring, screws and wrench; and 393691 Natural to LP gas conversion kit; also includes 3/4 in. angle flange

Approvals, American Gas Association IAS: AGA Design Certified: File no. L2025006; CGA Design Certified: File no. L2025006; UL Component Recognized: File no. MH5323

Approvals, Canadian Gas Association: UL Component Recognized: File no. MH5323

Fuel Type: Natural Gas

Body Pattern: Straight-Through

Voltage: 24v

Capacity (BTU): 130000

Inlet Size: 1/2"

Outlet Size: 1/2"

Ignition Type: Standing Pilot
