Resideo R8222V1003 - 24 V General Purpose Relay with DPDT Switching
Brand:
SKU
R8222V1003
Description:
Provide general purpose switching for refrigeration and air conditioning equipment, appliances, vending machines and similar applications.
Features:
Description: 24 V General Purpose Relay with DPDT switching
Coil Ratings Voltage: 24v
Switching: DPDT (1 P&1PDuty)
Electrical Connections: 1/4 in. quick-connect terminals
Electrical Ratings Contacts (Full Load): 3 A @ 480 Vac; 6 A @ 208 Vac, 240 Vac, 277 Vac; 12 A @ 120 Vac
Electrical Ratings Contacts (Locked Rotor): 18 A @ 480 Vac; 35 A @ 208 Vac, 240 Vac, 277 Vac, 60 A @ 120 Vac
Electrical Ratings Contacts (Resistive): 10 A @ 480 Vac; 20.8 A @ 120 Vac, 208 Vac, 240 Vac, 277 Vac
Pilot Duty Ratings: Minimum: Minimum: 3 VA @ 24 Vac, 120 Vac, & 480 Vac; Maximum: 25 VA @ 24 Vac, 125 VA @ 120 Vac, 240 Vac, & 480 Vac; Resistive: 3 A @ 277 Vac (0.75 power factor); Powerpile: (Normally Open Contacts Only) 0.25 A @ 0.25 to 12 Vdc
Frequency: 50 Hz, 60 Hz
Dimensions: 1-7/8 in. high x 2-5/32 in. wide x 2-3/8 in. deep
Temperature Ratings: -20 F to +155 F.
Application: Refrigeration
Voltage: 24v
Type: DPDT
